Features
• Horizontal configuration allows flexibility for single set-up, unmanned machining
• Ultra high positioning Accuracy: ±0.000079”/full stroke, Repeatability: ±0.000039”
• Ideal for both unmanned one-off and high quantity production
• Standard 20-station automatic pallet changer with up to 80 pallets available as an option
• Highest grade Meehanite cast iron construction with heavy duty roller linear guide way system
• High speed, built-in, dual contact 20,000rpm spindle
• Work handling system reduces pallet load & unload time, allowing for just-in-time operation
| X | 18.1" | 459.74 mm |
| Y | 20.1" | 510.54 mm |
| Z | 18.1" | 459.74 mm |
| # Axis | 5 | 5 |
| RPM | 20 RPM | 20 RPM |
| # ATC | 174 | 174 |
| Taper | NST No. 40 | NST No. 40 |
