Features
• Well suited for large part machining requiring increased rigidity and higher levels of precision and accuracy. Perfect for roughing and finishing of large cavities and cores in the die/mold industry.
• Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
• Rigid Meehanite cast iron construction with induction hardened solid box ways
• #50, Gear Driven, High Speed, High Torque 12,000rpm Dual Contact Spindle
• Patented double column bridge type design provides expansive work envelope and superior rigidity
• Linear scale feedback in X, Y, Z axes
• Ultra high speed and high precision contour control for smoother and faster machining. 2,800 block/sec. processing speeds
• 13,300 Lb table capacity provides added benefits for larger, heavier, more powerful machining
| X | 100" | 2,540 mm |
| Y | 63.6" | 1,615.4 mm |
| Z | 31.5" | 800.1 mm |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 40 | 40 |
| Taper | NST No. 50 | NST No. 50 |
| Table-W | 53.9" | 1,369.1 mm |
| Table-L | 118.1" | 2,999.7 mm |
