Features
• Ideal for ultra-high precision simultaneous 5-axis machining
• Positioning Accuracy: ±0.000039” Full Stroke, Repeatability: ±0.00002”
• High speed, 15,000rpm dual contact spindle
• Small & compact, saves on valuable floor space
• Optional pallet change systems available
• Linear scale feedback on all axes
• Highest grade meehanite cast iron construction with solid box ways
| X | 12.8" | 325.12 mm |
| Y | 20.1" | 510.54 mm |
| Z | 18.1" | 459.74 mm |
| # Axis | 5 | 5 |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 60 | 60 |
| Taper | NST No. 30 | NST No. 30 |
