| X-Axis | 27.6" | 701.04 mm |
| Y-Axis | 15.7" | 398.78 mm |
| Z-Axis | 11.8" | 299.72 mm |
| Power | 10.1 kW | 13.5 hp |
| RPM | 16,000 RPM | 16,000 RPM |
| # ATC | 21 | 21 |
| Taper | 7/24 #30 | 7/24 #30 |
| Table-W | 15.7" | 398.78 mm |
| Table-L | 31.5" | 800.1 mm |
| # Axis | 3 | 3 |
X Axis Travel: 27.6"
Y Axis Travel: 15.7"
Z Axis Travel: 11.8"
Rapid Rate X Axis: 1,969 IPM
Rapid Rate Y Axis: 1,969 IPM
Rapid Rate Z Axis: 2,205 IPM
Spindle Speed: 16,000 RPM
Spindle Taper: BT 30
Tool Changer: 21 ATC
Spindle Taper Air Blast and Back Washing System
Automatic Grease Lubrication System
Chip Shower System
150L Coolant Tank
Complete Covers
Safety Door Interlock System
System Enhancements:
Manual Pulse Generator
Work Light Kit (1-Light) w/Brackets
Table Size: 31.4" x 15.7"
Chip Conveyor
Coolant Thru Spindle
4th Axis Rotary Table
Nikken CNCZ180-LSA-BR2 Fourth Axis Rotary Table
