Structure
Hydraulic cylinder supports and ball joint. Adjustable cast iron guide arm. Allows for straight and miter cutting from 0 to +60 degrees
Mechanics
Gearbox designed to accept high lateral pressure (No thermal distortion). Motor driven blade brush
Blade
Inverter blade drive system. Hydraulic blade tensioning system. Carbide blade guides and bearings. Cosen's Save-A-Blade feature
Coolant
Adjustable flood coolant system. Additional coolant hose for work-bed and auger cleanup
Vising
Cast iron hydraulic vises. Hydraulic top clamps.
Interface
5.7" HMI touchscreen system that allows for controlled multiple indexing of material up to 999" in length. Automatic miter adjust. Feed pressure and feed rate valve system
| Weight | 4,675 lbs | 4,675 lbs |
Capacity Angle: 0 +45 +60
Round Capacity: 14" 13" 7.9"
Rectangular Capacity: 13" x 20" 13" x 13.7" 12.5" x 9"
Bundle w/ optional top clamps: Width: 1.18" - 20" Height: 1.96" - 13"
Blade Speed: 50 - 328 FPM
Blade Size (LxWxT): 16' 1" x 1.25" x .042"
Blade Motor: 5 HP
Coolant Motor: 1/8 HP
Coolant Tank Capacity: 16.1 gal
Hydraulic Tank Capacity: 9.5 gal
Workbed Height: 31.4"
Floorspace (LxWxH): 101.4" x 123.5" x 86.6"
