Structure
Hydraulic cylinder support with ball joint. Precision feed pressure and feed rate valve system for optimal cutting performance. Adjustable cast iron guide arm
Mechanics
Gearbox designed to accept high lateral pressure (No thermal distortion). Motor driven blade brush
Blade
Inverter blade drive system. Hydraulic blade tensioning system. Carbide blade guides and bearings. Cosen's Save-A-Blade feature
Coolant
Adjustable flood coolant system. Additional coolant hose for work-bed and auger cleanup
Vising
Cast iron hydraulic vise with split jaw to help reduce burr
Interface
5.7" HMI touchscreen system that allows for controlled multiple indexing of material up to 999" in length
| Weight | 3,300 lbs | 3,300 lbs |
Round Capacity: 10.2"
Rectangular Capacity (HxW): 10.2" x 11.8"
Blade Speed: 66 - 328 FPM
Blade Size (LxWxT): 12' x 1.25" x .042"
Blade Motor: 5 HP
Coolant Motor: 1/8 HP
Coolant Tank Capacity: 19.8 gal
Hydraulic Tank Capacity: 9.2 gal
Workbed Height: 28.37"
Floorspace (LxWxH): 85" x 86" x 60.2"
