C-1000NC

The Cosen C-1000NC is a robust automatic straight cut dual column bandsaw designed for rigorous industrial applications. Featuring a hydraulic dual column design, it ensures precision and stability during operation. The adjustable cast iron guide arm is powered hydraulically, enhancing cutting accuracy. It incorporates a durable gearbox that withstands high lateral pressure without thermal distortion, and a motor-driven blade brush for optimal cleaning.

This bandsaw is equipped with an inverter blade drive system, allowing for infinitely variable blade speeds ranging from 50 to 361 FPM, complemented by a hydraulic blade tensioning system for enhanced performance. The use of carbide blade guides and bearings further ensures reliability. A cast iron hydraulic vise with a split jaw is included to minimize burr formation during cutting. The user-friendly control interface, featuring hydraulic-powered controls and a dual valve feed system, enhances operational efficiency.

With a round and rectangular cutting capacity of 39.4 inches, the C-1000NC is a substantial machine, weighing in at 23,100 lbs. Its significant workbed height of 25.2 inches and spacious design, occupying a floorspace of 184.2" x 80.7", make it suitable for large-scale operations. The coolant system is efficient, featuring a 31.7-gallon tank, alongside a 26-gallon hydraulic tank, ensuring consistent operation. This bandsaw is a reliable investment for industries requiring high precision and efficiency.

Round Capacity: 39.4"
Rectangular Capacity (HxW): 39.4" x 39.4"
Blade Speed: 50 -361 FPM
Blade Size (LxWxT): 30' 10" x 2.625" x .063"
Blade Motor: 15 HP
Coolant Motor: 1/2 HP
Coolant Tank Capacity: 31.7 gal
Hydraulic Tank Capacity: 26 gal
Workbed Height: 25.2"
Floorspace (LxWxH): 184.2" x 80.7" x 138.2"
