Main Features
One-piece welded frame made from square pro le beams
Entire assembly is machined in one position on Soitaab’s 16 ft. x 65 ft. CNC boring and milling machine
Integrated cutting table is completely stand-alone
Table is divided into sections focusing fume extraction under the torches
Table dampers automatically opened in 2 lateral channels
Side access scrap drawers for easy scrap removal
Servo-driven plasma carriage controlled by the CNC
Z axis with automatic arc voltage height control (AVC)
TAG automatic initial positioning by touch sensing or Ohmic contact for thin materials
Magnetic torch breakaway anti-collision device
Soitaab Human Machine Interface (SHMI)
Touch screen monitor with user friendly CNC control
Working Area: from 1,5m x 3m up to 3m x 14m
Carriage Stroke z axis (vertical): 300 mm
Motors ( x, y , z ): Brushless
Driver ( x, y , z ): Digital
Positioning Speed: 70 m/min
Repeatability - +: 0,05 mm/m
CNC: Soitaab CNC
Monitor: 15” Touch Panel Screen
Data Communication: USB - Ethernet - LAN
Cutting Technologies: Plasma
