| X | 23.6" | 599.44 mm |
| Y | 15.7" | 398.78 mm |
| Z | 15.7" | 398.78 mm |
| Dimensions | 101" x 108" x 129" | 101" x 108" x 129" |
| Weight | 8,900 lbs | 8,900 lbs |
Specifications (subject to buyer verification):
X Travel: 23.6"
Y Travel: 15.7"
U Travel: 4.7"
V Travel: 4.7"
Z Travel: 15.7"
Maximum Workpiece Dimensions: 35.4" x 29.5" x 15.7"
Maximum Workpiece Weight: 3,330 lbs
Maximum Taper Angle: ± 30º / 87 mm, ± 27º / 100 mm, ± 45º / 40 mm
Standard Wire Diameters: 0.004" to 0.013"
Optional Wire Diameters: 0.003"
Wire Guides" Closed-Type, Diamond
Wire Spool: Up to 35.6 lbs (DIN200)
Minimum Diameter of Threading Hole: 0.019"
Dielectric Paper Cartridges: 2
Dielectric Capacity: 317 Gallons
Equipped With (subject to buyer verification):
Automatic Wire Threader
Chiller
