| X | 23.6" | 599.44 mm |
| Y | 15.7" | 398.78 mm |
| Z | 11.41" | 289.81 mm |
| Submerged (Yes/No) | Yes | Yes |
| Control | CNC | CNC |
| Dimensions | 38.9 x 24.4 x 11.4 | 38.9 x 24.4 x 11.4 |
| Weight | 8157.10 | 8157.10 |
Specifications (subject to buyer verification):
Max.Workpiece dimension: 38.9 x 24.4 x 11.4 in
Max. Workpiece weight: 39.37 in
Max. Workpiece height: 11.41 in
X/Y axis traveling: 23.6 / 15.7 in
Z axis traveling: 11.41 in
Wire size range: 0.007, 0.009, 1.1 in
Wire spool: 35.27 lb
Working table: U Shape
Max. Tapper: ±21º / 3.93 in
Machine power consumption: 15 KVA
Max. Axes speed: 31.49 in/min
Wire guide type: Closed type
Glass scales resolution on X and Y axis: 0.1 μm
Encoder in U, V and Z axis: 0.1 μm
Best Rougness: 0.4 Ra
Filter: Cartridges
Filtering quality: 3 μm
Cutting technology: Flushing and submerged
Foot print W x D x H: 117.3 x 118.1 x 81.2 in
Total machine weight: 8157.10 lbs
Water capacity: 850 Litres
Resin capacity: 14.4 Litres
Equipped With (subject to buyer verification):
AWT function
Anticollision function
Autolubrication system for X and Y axis
Linear Motors X and Y axis
