| Swing | 31.5" | 800.1 mm |
| Machining Length | 78.75" | 2,000.2 mm |
| Chuck Size | 21" | 533.4 mm |
| Bar Capacity | 6.25" | 158.75 mm |
| Power | 40 hp | 29.8 kW |
| Max RPM | 1,800 RPM | 1,800 RPM |
| Turning Dia | 23" | 584.2 mm |
| Tailstock | Yes | Yes |
| Live Tooling | Yes | Yes |
| Control | CNC (Fanuc 0iTF Plus Control) | CNC (Fanuc 0iTF Plus Control) |
Specifications (subject to buyer verification):
Swing over bed: Ø940mm
Swing over saddle: Ø620mm
Max. Cutting Diameter: Ø600mm
Standard Cutting Diameter: Ø274.7mm
Max. Cutting Length: 2,000mm
Chuck Size (Main): Chuck Size (Main): 21"
Type of Spindle Nose: A2-15
Max. Spindle Speed: 1,500 RPM
Through Spindle Hole Diameter: Ø165mm
Max. Bar Size: Ø165mm
Spindle Bearing Inner Diameter: Ø240mm
Spindle Motor: 45 / 37 (Opt.: 60 / 50)
Spindle Torque: 4,108Nm
Number Tool Station: 12
Tool Size (Out Dia. x Boring bar size): □32 × Ø60
Turret Indexing Time sec/step: Index: 1.8 Rotation: 0.5
Rapid Traverse (X / Z / Y): 20 / 20 / 10 m/min
Max. Stroke (X / Z / Y): 360 / 2,200 / ±80 mm
Feed Motor (X / Z / Y): 4 / 7 / 4 kW
Tailstock Stroke: 2,150mm
Cylinder Dia.: Ø120mm
Quill Stroke: 150mm
Quill Taper: #5
Spindle Motor: 7.5 / 5.5 (Opt.: 11 / 7.5)
Max. Spindle Speed: 3,000 RPM
Max. Drill/Tap Size (Endmill / Collet size): Ø32 / ER 40mm
Min. Index Angle: 0.0001 deg.
Tool Holder: BMT 75
Lubrication Tank Capacity: 12L
Hydraulic Tank Capacity: 50L
Coolant Tank Capacity: 300L
Electrical Power Supply: 75kVA
Floor Space (L x W): 7,130 x 2,160mm
Height: 2,600mm
Weight: 13,100 kg
Equipped With (subject to buyer verification):
Fanuc 0i-TF Plus Controller
