Cat50 Big Plus Spindle
40 Position Automatic Tool Changer
Box Ways Construction
290 psi Thru-Spindle Coolant
Probe Ready
| X | 82" | 2,082.8 mm |
| Y | 40" | 1,016 mm |
| Z | 32" | 812.8 mm |
| Power | 35 hp | 26.1 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 40 | 40 |
| Taper | CT50 | CT50 |
| Table-W | 88" | 2,235.2 mm |
| Table-L | 40" | 1,016 mm |
| # Axis | 4 | 4 |
| Control | CNC (Fanuc 0i-MF Plus Control) | CNC (Fanuc 0i-MF Plus Control) |
| Dimensions | 234" x 157" | 234" x 157" |
| Weight | 35,273lbs | 35,273lbs |
SMART PACKAGE: ▪ 290 PSI Coolant Thru-Spindle
▪ Oil Skimmer
▪ Full Enclosed Splash Guard
▪ Built-in Dual (Internal) Screw Conveyor
▪ Coolant Bed Flush
▪ Renishaw Probe Ready Kit (OMI-2T)
▪ 4th Axis Preparation
▪ Rigid Tapping
▪ Big Plus Spindle
▪ Manual Guide
