Corrosion Resistant 30,000 Gallon FRP Tank | Augusta Fiberglass Process Storage

Corrosion Resistant 30,000 Gallon FRP Tank | Augusta Fiberglass Process Storage. 13'-6" diameter X 28' high straight side. Internal rated atmospheric at 110 F. Specific Gravity 1.1. Resin 9102, Hetron 922 or Equal. Surfacing Veil (1) ply "C" Glass Corrosion liner 100 mils. Exterior color gray with UV inhibitors. Flat top, flat bottom. Top fittings: 24" manway, (1) 8" center agitator nozzle, (1) 6" vent, (3) 4" and (2) 6". 24" side bottom manway, 6" side top overflow outlet. (2) 6" and (1) 8" siphon drain that is 2" from tank floor. (3) 4" side bottom outlets. Tank has (4) internal baffles and carbon steel top bridge for agitator. Built 2015.

Used Equipment Facts About This Machine
Manufacturer: Augusta Fiberglass
Equipment Type: FRP Storage Tank / Fiberglass Process Tank
Capacity: 30,000 Gallons
Condition: Unused
Year Built: 2015

Description
Unused Augusta Fiberglass 30,000 gallon FRP storage tank designed for industrial liquid storage and process applications requiring corrosion-resistant fiberglass construction. Engineered for atmospheric service, this large-capacity tank is suitable for chemical processing, water treatment, industrial liquid storage, and corrosive fluid handling operations.
The tank features fiberglass reinforced plastic (FRP) construction with a corrosion-resistant liner system consisting of a surfacing veil and 100 mil “C” glass corrosion liner. Manufactured using Resin 9102, Hetron 922, or equivalent materials, the vessel is designed for fluids with a specific gravity up to 1.1 and operating temperatures up to 110°F.
The tank includes numerous process nozzles, internal baffles, side manways, siphon drains, and a carbon steel top bridge for agitator mounting. The exterior is finished in gray with UV inhibitors for outdoor durability and weather resistance.

Specifications

Manufacturer: Augusta Fiberglass
Type: FRP storage tank
Capacity: 30,000 gallons
Construction: Fiberglass reinforced plastic (FRP)
Condition: Unused
Year Built: 2015

Dimensions

Diameter: 13’ 6”
Straight Side Height: 28’

Design Conditions

Internal Rating: Atmospheric
Maximum Temperature: 110°F
Specific Gravity Rating: 1.1

Resin & Liner Construction

Resin: 9102, Hetron 922, or equal
Surfacing Veil: (1) ply
Corrosion Liner: 100 mil “C” glass
Exterior Color: Gray with UV inhibitors

Tank Design

Flat top
Flat bottom
(4) internal baffles
Carbon steel agitator bridge

Top Connections & Fittings

(1) 24” manway
(1) 8” center agitator nozzle
(1) 6” vent
(3) 4” nozzles
(2) 6” nozzles

Side Connections & Drains

(1) 24” side bottom manway
(1) 6” side top overflow outlet
(2) 6” siphon drains
(1) 8” siphon drain
Siphon drains positioned approximately 2” from tank floor
(3) 4” side bottom outlets

Applications
Ideal for chemical storage, water treatment, industrial process liquids, and corrosive material handling applications.

Products This Equipment Would Be Used For

Process water
Chemical solutions
Wastewater treatment liquids
Corrosive fluids
Industrial brine solutions
Liquid fertilizers
Sodium hypochlorite
Caustic solutions
Industrial wash water
Bulk liquid storage
