NEW AMOB GROUP EMOB SERIES FULLY ELECTRIC TUBE BENDING MACHINE

The AMOB eMOB Series Fully Electric Tube Bending Machines deliver advanced CNC bending technology for high-precision tube and pipe fabrication. Designed for maximum efficiency and flexibility, these fully electric machines process round and special section tubes from 5 mm up to 225 mm OD with exceptional repeatability and minimal ovality.

With multi-radius bending, multi-stack tooling capabilities, automatic spring-back compensation, and advanced motion control systems, the eMOB series is ideal for demanding production environments requiring speed, accuracy, and energy-efficient operation.

Tube Capacity: 5 mm – 225 mm OD
Machine Type: Fully Electric CNC Tube Bender
Bending Capability: Fixed & Variable Radius Bending
Bending Direction: Left or Right
Tool Capacity: Multi-Stack up to 8 Tools
Minimum CLR Capability: Less Than 1xD
Material Compatibility: Round & Special Section Tubes
Axis Control: Full Axis Interpolation
Spring-Back Compensation: Automatic
Motion Control System: Electronic CNC Monitoring System

AVAILABLE MODELS
eMOB 42 — Up to 42 mm
eMOB 52 — Up to 52 mm
eMOB 63 — Up to 63 mm
eMOB 80 — Up to 80 mm
eMOB 100 — Up to 100 mm
eMOB 130 — Up to 130 mm
eMOB 150 — Up to 150 mm
eMOB 180 — Up to 180 mm
eMOB 225 — Up to 225 mm

Fully Electric CNC Bending System
Multi-Stack Tooling Capability
Automatic Spring-Back Compensation
In-Cycle Correction System
Tooling Configuration Storage
Anti-Collision System
Electronic Motion Control Monitoring
Full Axis Interpolation
Carriage Booster Positioner
High-Rigidity Bending Head
Left & Right Bending Capability
Real-Time Diagnostics & Warning System
