Doosan Puma 400C – 2007

Doosan Puma 400C CNC Turning Center

Swing Over Bed30.3”
Swing Over Saddle23.23”
Max. Machining Dia.21.7”
Max Work Length40.3”
X-Axis Travel14.3”
Z-Axis Travel43.5”
Speed Range15 – 1,500 RPM
Spindle NoseA1#15
Spindle Bore Diameter7.1”
Bar Capacity6.5”
No. of Turret Stations12
Spindle Motor50 HP (30 min)
Spindle Speed1500 RPM

Fanuc Series 21iTB
3-Jaw Chuck
Tailstock
Chip Conveyor
Tool Presetter
