-Model: 1.5 - 1766192
-Capacity: 60" x 0.015" to 0.075"
-Number of Work Rolls: 17, 8 over 9
-Diameter of Work Rolls: 1.50"
-Width of Rolls: 66"
-Backup Rolls: 5 Flights Top and Bottom
3 Middle Flights - Motorized Adjustment
5 Bottom Flights - Fixed
-Entry and Exit Driven Pinch Rolls
-Pinch Roll Diameter: 6"
-Main Drive Motor: 50 HP DC, 1800 RPM
-D.O. James Reducer w/4.5:1 ratio
-Line Speed: 150 FPM Max. approx.
-Line Direction: Right to Left
