| X | 19.7" | 500.38 mm |
| Y | 13.7" | 347.98 mm |
| Z | 16.8" | 426.72 mm |
| Max. Workpiece Dimensions | 41.3 x 25.6 x 16.5" | 41.3 x 25.6 x 16.5" |
| Max. Workpiece Weight | 880 Lbs. | 880 Lbs. |
| Auto Threading (Yes/No) | Yes | Yes |
| Submerged (Yes/No) | Yes | Yes |
| Taper Angle | 30 | 30 |
| Taper Height | 3.0 | 3.0 |
| U-V Travels | +/- 2.75" | +/- 2.75" |
| Control Type | Agievision | Agievision |
| Screen Size | 15 | 15 |
| Program Input Methods | Keyboard, USB, Ethernet | Keyboard, USB, Ethernet |
