H Beam Shot Blasting Machine in Shaoxing City, China

H-beam Shot Blasting Machine JPG
JPG H-beam shot blasting machine is designed and manufactured to clean the surface of the section steel. It is ideally suited for removing the rust, scale and contamination from the steel surface, which can make the surface clean, bright but with a certain coarseness. So the paint film can attach to the steel surface more firmly, thus improving surface quality and the anti-corrosion capacity. We, a famous H-beam shot blasting machine manufacturer in China, can design and manufacture different specification according to different requirement of the client.
Technical Specifications of H-beam Shot Blasting Machine
Item
Parameter

Accessible section dimensions(W×H×L)
1200×2500×20000mm

Effective clean section area(W×H)
1200×2500mm

Productivity
1.5~3 m/min

Surface cleanness A-B
Sa2~Sa2.5(GB8923-88)

Surface roughness
15~50µm(GB1030-83)

Impeller head
PD-11 impeller head

Quantity
12 sets

Max. shot blast capacity
220×12=2640kg/min
