Length of the main part
About10500*1650*1500mm
Weight of main part
About 9.5 ton
Voltage
380V/50HZ/3Phase (as customer`s request)
Roller fixer
Middle plate welded
Frame
350H steel welded
Middle plate thickness
20mm/18mm/16mm/14mm/12mm
Drive mode
Chain Drice//Gear Drive
Material of rollers
45# steel, surface hard chromium plating.
Material of shafts
45# steel
Diameter of shafts
Φ80mm(depend on different design)
Number of rollers:
29 rollers
Main power
5.5kw
Cutting&Hydraulic
Double guide pillar
Hydraulic motor power
3kw,4kw
Hydraulic Pressure
10-12MPa
Cutting drive
Decelerating motor + Chain drive gear all by high-frequency
Control System
PLC system: Mitsubishi, Panasonic,Dental,Siemens,Schneider
Feeding Material width
Better as your drawing or from our designer
Feeding Thickness
0.8~1.5mm
Effective width
Better as your drawing or from our designer
Productivity
8-12/min
Package of machine
Waterproofing membrane, standard export packing
