Rolled material
0.3-0.8mm thickness, aluminium sheet, galvanized sheet, colored steel sheet and various steel plates
Effective width
as drawing
Feeding width
as drawing
Forming steps
15 steps
Roller
45# forged steel, hard chrome plating within 0.05mm
Diameter of shaft
75mm
Main frame
350H steel
Main motor power
4 kw
Pump power
4kw
Medium plate thickness
16mm
Sprocket chain
1 inch
Drive type
by chain
Cutting Blade
Cr12, heat treatment 60-62°C
Frequency Converter
It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm).
