1
Width of feeding material
As the tile profile
2
Thickness of feeding material
0.85 mm coil sheet
3
Roller station
13 stations
4
Shaft Diameter
60 mm
5
Productivity
20-55 m/min
6
Rollers' material
45# steel with 0.05mm chrome
7
Shaft material
45# steel with 0.05mm chrome
8
Weight
2.8 tons
9
Size
5.6*1.1*1.3m
10
Voltage
240v/380V/410v/440v 50/60Hz 3phases
11
Control
PLC
12
Decoiler
3 tons
13
Motor
5.5 kw
14
Driving way
Chain transmission
15
Chain size
1.2 inch
16
Cutting system
Hydraulic cutter
