Metal Building Trim Roll Forming Machine Connecticut

Metal Building Trim Roll Forming Machine – Connecticut, USA

High-Speed Custom Trim Machine for Flashing & Architectural Metal Profiles
The Metal Building Trim Roll Forming Machine located in Connecticut, USA, is a high-performance, fully customized solution designed for the commercial and residential metal construction industry. Built for precision, speed, and flexibility, this machine is capable of producing a wide range of architectural metal trims and flashings with consistent accuracy.
Industry Applications

This machine is ideal for businesses operating in the metal building construction, roofing, siding, and architectural sheet metal industries. It supports contractors, fabricators, and metal building component suppliers across the state of Connecticut and surrounding regions, who require precise and versatile trim profiles for various construction projects, including warehouses, homes, commercial buildings, and agricultural structures.
Whether you’re fabricating drip edges for residential roofs or custom flashing components for large metal buildings, this machine delivers consistent results with high output speed and long-term reliability.
Frequently Asked Questions
Q: What types of materials can this machine form?

A: This particular configuration is designed for aluminum trim production. For steel or galvanized applications, we offer similar machines built to handle different material specifications.
Q: Can I request multiple trim profiles on the same machine?

A: Yes. We can configure the machine for quick-change tooling or adjustable dies depending on the number of profiles and changeover frequency.
Q: What support do you offer for setup in Connecticut?

A: We offer full setup, commissioning, and training support, including remote and on-site services. Our technicians ensure the machine is ready for production from day one.
Q: Is the machine compliant with U.S. electrical and safety standards?

A: Yes. All machines are built to meet U.S. 240V 3 Phase 60Hz electrical standards and include full safety covers and E-Stop systems.
Q: How long does it take to receive the machine after ordering?

A: Lead times vary based on the complexity of customization but typically range between 8–14 weeks. Contact us for real-time availability and production slot booking.
Q: Do you offer machines for other building components?

A: Absolutely. We supply machines for roof panels, purlins, tile sheets, wall cladding, and more. Let us know what you're looking for.
For more details or to begin your machine quote process, contact [email protected] today.

Forming Speed: 70 – 80 ft/min
Material: Aluminum
Material Thickness Capability: Suitable for standard aluminum trim gauges
Machine Weight: 7 tons
Machine Footprint: 31 ft (length)
Main Power: 8 HP
Motor Configuration: 240V / 3 Phase / 60Hz
Drive System: Chain Drive with Gearbox
Roll Forming Stations: 24
Cutting Type: Electric Shear – fast, clean cuts for high-volume runs
Control System: Delta CNC system – programmable and easy-to-operate interface
Safety Features:
Full safety covers
Emergency Stop (E-Stop) buttons for operator safety
Full safety covers
Emergency Stop (E-Stop) buttons for operator safety
Step Flashing
Apron Flashing
Valley Flashing
Drip Edge Flashing
Counter Flashing
Kick-Out Flashing
Roof-to-Wall Flashing
Skylight Flashing
Window and Door Flashing
Deck Flashing
Cap Flashing
Ridge Cap
Eave Trim
Gable Trim
Endwall Flashing
Z-Flashing
J Trim
Fascia Trim
Soffit Trim
And more – custom profiles available
Machine Sales
Maintenance & Repair
Setup & Adjustment
Operator Training
Ongoing Technical Support
Decoilers
Coil Handling Systems
Profile Adjustments
Automatic Stacker Systems
Remote PLC Integration
Inline Notching or Punching Units
Metal roof panel machines
Metal flashing & trim machines
Purlin machines
Slitting lines
Metal tile forming machines
Uncoilers, coil cars, embossers, and more
