Size
8900mm X 2230mm X 2300mm (With Single Axle 4 Tires)
Total Weight
About 10 Ton
Thickness of Bending Leaf
10mm thickness, processed by CNC
Cutting Blade
12CrMov Material, Heat Treatment
Cutting Type
Mechanical Cutting
Forming Type
Roll-Formed and Length-Set Cutting
Power
Total Motor Power : 17.5KW
Main Motor Power : 7.5KW
Bending Power : 3.0KW+1.5KWx2
Cutting Power : 4.0KW
Seaming Power
1.1KW+1.1KW
Roller Material
45# High-Quality Steel, Quenched HRC 55~65, Hard Chrome Plating
Shaft Material
45# High-Quality Steel, Galvanized
Stand of Molding
13+1 Steps
Feeding Width
914mm
Effective Width
610mm
A K-span roll forming machine is a specialized piece of equipment used in the construction and manufacturing industries to create K-span or arch-type metal roofing and building components. This machine can produce continuous, curved metal sheets that are highly durable and suitable for a variety of applications, including warehouses, agricultural buildings, and storage facilities.
Key Features and Benefits of K-Span Roll Forming Machines:
Continuous Production: K-span machines produce long lengths of metal sheets in a single pass, reducing the need for seams and improving structural integrity.
Customizable Profiles: They can be designed to produce various profiles and thicknesses, allowing for customization based on specific project requirements.
High Efficiency: These machines are capable of operating at high speeds, resulting in faster production times and reduced labor costs.
Durability: K-span products are typically made from high-strength materials, ensuring they can withstand harsh weather conditions and provide long-lasting performance.
Versatility: Suitable for various applications, including roofing, walls, and arch structures, making them popular in both industrial and commercial sectors.
Easy Operation: Many K-span roll forming machines are equipped with user-friendly controls, making them accessible for operators with different levels of experience.
Applications:
Agricultural Buildings: Used for barns, storage facilities, and equipment sheds.
Industrial Structures: Suitable for warehouses and manufacturing plants.
Commercial Buildings: Ideal for retail spaces and office buildings.
Conclusion:
K-span roll forming machines are an efficient and effective solution for producing high-quality metal roofing and building components. Their ability to create durable and customizable products makes them a valuable investment for construction and manufacturing businesses looking to enhance their capabilities.
