Main motor power: 22kw
Station: adopt cast iron HT50
Drive: Gear box driving
Main shaft dia:￠120mm, material: 45﹟forge steel
Roller material: GCR15 quenched 58°-62°,chromed
Roll station: about 15 stations
Material thickness: 2.5-4.0mm
Machine speed: about 3-5m/min
Power supply: 380V 50HZ, 3 phases
Control system: PLC with touch screen
