1
Suitable material
galvanized steel coil
2
Thickness of coil sheet
0.3-0.5mm
3
Coil width
as customer's profile drawing requirement
4
Effective width
as customer's profile drawing requirement
5
Material of main frame
welded by square pipe
6
Diameter of Soild shaft
40mm, high grade 45# steel
7
Roller
Cr12
8
Thickness of middle plate
Memorial archway
9
Forming station
8+1 rows
10
Drive type
Gear
11
Power of main motor
4.0 kw, Lichao, Shanghai, with reducer
12
Servo motor
2.2KW Touch-win
13
Forming speed
About 25-30m/min
14
Hydraulic pump station
4.0 kw, 46# hydraulic oil
15
PLC
Touch-win
16
Material of cutting blades
Cr 12 Mov, quenching 58-62°C
17
Frequency converter
It has the advantage of slowing down before cutting, to
ensure the length accuracy ±1mm, far better than
industrial standard ±3mm.
18
Switch
CHNT
