Specifications
Coil Width
according to drawings
Diameter of shaft
70mm
Forming Speed
8-12meters/min
Middle plate
16mm
Material of shaft
45#steel with tempering
forming thickness
0.2mm-0.6mm
material of rollers
45#steel
Cutting type
hydraulic -cutting
Main power
4kw+3kw
Main frame
300H steel
Control system
PLC
Brand of electrical parts
Delta
Manual decoiler
5 tons
Power
3 Phase,380 Voltage,50Hz
Dimensions(L*W*H)
About 6.5*1.2*1.2M
Weight
about 3 tons
