Rolling Speed: about 30-40m/min
Materials to be processed: Galvanized steel, Aluzinc, PPGI from 0.3 mm to 0.8 mm
Maximum length of the sheet to be unloaded: 6 m
Control System: PLC with touch screen
Roller Stations: about 20 stations
Roller Material : 45# forge steel, coated with chrome
Shaft Material and DIA: ￠76mm,material is 45# forge steel, Chrome with quenching
Motor Power: 22kw main motor
Hydraulic power:7.5kw
Power supplier:380V, 50HZ,3 phase
Way Of Drive:Gearbox
The size of the forming machine: About 11,500*1700*1200mm
Machine weight: about 10 tons
