2017 Haas Mini-Mill EDU CNC VMC, 4000rpm Spindle, 10 Station ATC, 16" x 14" x 15" X/Y/Z Travels.
| X | 16" | 406.4 mm |
| Y | 12" | 304.8 mm |
| Z | 10" | 254 mm |
| Power | 7.5 hp | 5.6 kW |
| RPM | 4,000 RPM | 4,000 RPM |
| # ATC | 10 | 10 |
| Taper | CAT-40 | CAT-40 |
| Table-W | 12" | 304.8 mm |
| Table-L | 36" | 914.4 mm |
| # Axis | 3 | 3 |
| Control | CNC (Haas) | CNC (Haas) |
| Dimensions | 65" x 75" x 93" | 65" x 75" x 93" |
| Weight | 4500lbs | 4500lbs |
16" X-Axis Travel
12" Y-Axis Travel
10" Z-Axis Travel
12" x 36" Table Size
4000rpm Spindle Speed
CAT-40 Spindle Taper
65" x 75" x 93" LxWxH
4500lb Machine Weight
220V-3P Power
The Haas Minimill-EDU is a stripped down version designed for education purposes, meaning none of the options that might normally see. The EDU has the same platform, control and software as a Mini-Mill would. It just won't have options like coolant system, rigid tapping, etc... Most of which can be added in the field.
Mint Condition and Very Low Hours
10 Station Automatic Tool Changer
Ethernet Interface
