USED 2001 AWECO BPS 16.600A

Power voltage: 3x400V 50 Hz
Power input: 605 kVA
Electrical connection sizing: min 300 A
Dimension: 2450 x 1985 x 1245 mm
Weight: 4600 t

Water cooling
The equipment consists mainly of the following parts:
Frame in a portal arrangement

Sixteen pneumatic welding heads with a spacing of 100 and 125 mm and opposing lower electrode holders

Safety barriers
Four 150 kVA welding transformers
Final stages for transformer control
Control cabinet with programming and technological units
