Control system: Heidenhain TNC 415
Length of the working table: 1600 mm
Width of the working table: 630 mm
Workpiece weight: 1000 kg
Maximum rotary speed of the vertical spindle: 3200 rpm
X-Axis travels: 1250 mm
Y-Axis travels: 700 mm
Z-Axis travels: 500 mm
Taper: ISO 50
Machine height: 2410 mm
Machine length: 4400 mm
Machine width: 3615 mm
Machine weight: 7100 kg
