Control system: HEINDENHAIN iTNC 530
Total hours: 31700 h
Hours on: 30135 h
Length of the working table: 400 mm
Width of the working table: 400 mm
Maximum table load (evenly distributed): 300 kg
Power of the spindle drive: 12 kW
Maximum spindle speed: 10000 1/min
Number of axis: 4 pcs
X-Axis travels: 560 mm
Y-Axis travels: 510 mm
Z-Axis travels: 560 mm
Taper: SK 40
Spindle diameter: 75 mm
B: 360
Number of stack positions: 45 pcs
Number of pallets: 2
Machine length: 5307 mm
Machine width: 4430 mm
Machine weight: 8500 kg
Rotary table
Tool holders
LOSMA high-pressure cooling
APC - two-pallet automatic change
2008: spindle replacement
2019: high-pressure pump replacement
2024: CYTEC collet replacement in the table
