Honeywell M7284A1004 Modutrol IV Actuator Motor, 120V 50/60HZ 15VA, 150 lb-in [New]

Application Type: Electric. Internal Auxiliary Switch: 0. Fail Safe Mode: Non-Spring Return. Shaft Shape: Square. Mounting: Foot-Mounted. FEATURES: Integral spring return returns motor to normal position when power is interrupted. Integral junction box provides NEMA 3 weather protection if the motor is mounted in the upright position. Motor and circuitry operate from 24 Vac. Quick-connect terminals are standard--screw terminal adapter is available. Adapter bracket for matching shaft height of older motors is available. Motors have field adjustable stroke (90 to 160 degrees). Integral auxiliary switches are available factory mounted, or can be field added. Spring return motors can operate valve linkages from power end or auxiliary end shafts for normally closed or normally open valve applications. All models have dual shafts (slotted and tapped on both ends). All models have auxiliary switch cams. Fixed torque throughout the entire voltage range. Motors are designed for either normally open or normally closed valves and dampers. Models available with adjustable start (zero) and span. SPECIFICATIONS: Description Modutrol Motor. Control Signal Modulating, 4-20 mA. Feedback No. Motor shaft Dual-ended shaft. Stroke Adjustable; 90 to 160 degrees, Symmetrical. Torque Rating (lb-in.) 150 lb-in. Torque Rating (Nm) 17 Nm. External Auxiliary Switches Available Yes. Voltage 120V. Frequency 60 Hz. Frequency 50 Hz. Power Consumption Driving (VA) 15 VA. Electrical Connections Screw terminals. Shaft Dimensions (in.) 0.375 in. Shaft Dimensions (mm) 10 mm. Weight (lb) 7.5 lb. Dimensions (in.) 6 7/16 in. high x 5 1/2 in. wide x 7 5/16 in. deep. Dimensions (mm) 164 mm high x 140 mm wide x 185 mm deep. Temperature Range, Ambient (F) -40 F to +150 F. Temperature Range, Ambient (C) -40 C to +60 C. Deadweight Load on Shaft (Either End) (lb) 200 lbs. Deadweight Load (Combined on both Shafts) 300 lbs. Nominal Timing (sec) 30-60 sec. Shaft Rotation (upon control signal increase) Clockwise (as viewed from power end) (normally closed). Auxiliary Switch Ratings AFL - 120 Vac 7.2 A. Auxiliary Switch Ratings AFL - 240 Vac 3.6 A. Auxiliary Switch Ratings ALR- 120 Vac 43.2A. Auxiliary Switch Ratings ALR- 240 Vac 21.6 A. Approvals, Underwriters Laboratories Inc Listed File: E4436, Guide: XAPX. Approvals, Canadian Standards Association Certified: File No. LR1620, Guide No. 400-E. Approvals, CE EN55011 (Emission) EN50082-2 (Immunity) 73/23/EEC (LVD). Includes Transformer and Screw Terminal Adapter.. Honeywell. Honeywell. M7284A1004.
