Raw material
Galvanized steel coil
Material thickness
1.2-2.5mm
Roller stations
12
Shaft material
High grade 45# steel
Shaft diameter
75mm solid
Roller material
High grade 45# steel
Middle plate thickness
20mm
Machine size
6*1.2*1.5m
Productivity
8-15m/min
Material
CR12
Method
Hydraulic cutting
Driving way
Chain 2inch
Motor
11KW
Hydraulic oil pump
5.5KW
Voltage
380V,50HZ ,3 PHASE or customize as your need
PLC
Delta from Taiwan
Invertor
Delta from Taiwan
Screen
Touch screen ,Delta
Encoder
Omron from Japan
Language
Chinese & English or as your request
