Packaging:Nude
Productivity:200 stes/ year
Brand:Yingyee Machinery
Transportation:Ocean
Place of Origin:China
Supply Ability:200 stes/ year
Certificate:ISO9001
HS Code:73079100
Port:Tianjin Xingang
Suitable Plate Material: thickness 1.5-2.0mm, Galvanized steel or blank steel
Working Speed: 12-15 meters / min
Forming Steps: according to different profiles, changing by 5 sets cassettes
Material of Roller: Gcr15, Quench HRC58-62 Plated Chrome
Material of Shaft: 45# Advanced Steel (Diameter: *76mm), thermal refining
Driven system: Chain Driven 1.5 inches 20A
Main Power with reducer: 15KW WH Chinese Famous
Cutting: Hydraulic Cutting Cr12mov
Material of Cutting Knife: Cr12Mov, Quench HRC58-62
Hydraulic Station Power: 11KW Wuxi Wanshen Famous Chinese Brand
The whole machine is controlled by industry computer-PLC.
PLC–Panasonic, Japan
Touch Screen–Panasonic Japan
Encoder–Omron, Japan
Electric parts–Schneider
