Rows of rollers 22 rows
Roller material 45# steel with CNC machining, plated hard chromium surface
Diameter of shaft ¢70mm
Material of main shaft 45# steel with grinding process and then slack quench processed
Frame welded with 350H section steel
Wall panel thickness 16mm
Main motor power 7.5KW
Hydraulic station power4KW
Main electrical control system Delta PLC
Material of cutter Cr
MoV with hard treatment, HRC 52-681
Driving mode single chain 1 inch
Productivity 8-10m/min
Power supply 380V, 60HZ, 3 PHASES
Dimensions of major structure 10240mm*800mm*900mm (approximate)
