Configurations
Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Machine Of Roll Forming ,Electric-Motor, Glazed Tile Pressing Device ,Cutting Device ,Hydraulic Station ,PLC Control, Supporter Table.
Control System
PLC Delta Inverter
Main Frame
400mm H-Beam
Main Power
4 kw
Pump Power
3 kw
Power Supply
380V, 3-Phase,50Hz
Forming Speed
4-8m/min
Roll Station
16 stands
Roller Diameter
65mm
Hydraulic Pressure
10-12MPa
Forming Size
260mm
Feeding Thickness
0.27-0.8mm
Feeding Width
600mm
Backboard Thickness
18mm
Chain Size
33mm
Cutter Standard
Cr12
Roller Standard
Cr12
Cr-Plating Size
0.05mm
Overall Size
6000 × 1000 × 1200mm
Total Weight
3T
