Roller material
45#Chrome steel
Shaft diameter (mm)
about 55mm
Working speed(m/min)
About 1500-2000mm/min
Step distance
Adjustable according to requirement
Speed adjusting mode
AC Frequency
Roller drive
Decelerating motor + Chain drive
Cutting mode
Hydraulic cutting
Cutter material
Cr12 mold steel
Length measurement
Encoder
Control mode
Mitsubishi PLC
Operating mode
Button + Mitsubishi Touch screen
Main motor power(kw)
4.0KW (Depend on final design)
Hydraulic station power
7.5K W (Depend on final design)
Uncoiler's loading capacity
Max. Capacity: 3000kgs
