GI or PPGI
0.7-1.2MM
Roller material
High grade 45# steel with Cr12 quenched
Shaft material
High grade 45# steel with Cr12 quenched
Shaft diameter
50mm
Roller stations
14
Middle plate thickness
16mm
Machine size
5*0.8*1.2m
Productivity
8-15m/min
Material
GCR12
Method
Hydraulic cutting
Driving way
Chain 1 inch
Motor
4KW
Hydraulic oil pump
3KW
Voltage
380V,50HZ ,3 phase or customized as your need
PLC ,invertor
Delta from Taiwan
Screen
Delta ,touch screen
Encoder
Omron from Japan
Language
Chinese & English or as your request
