18-20m/min, good quality
Mainly forming system
Main power:5kw, hydraulic power：5.5kw
6 electronicmotors auto adjust size.
Frame：500mm H frame steel
Forming speed: 18-20m/min
Shaft material and diameters: #45 steel and fit side 65mm. flexibleside:85mm
Roller material: Gcr15. the hardness is HRC 52-55
Steps: 15 steps for forming
All size change by PLC. All parameter set from the PLC control system
C/Z change, by manual change the rollers discretion
Machine structure：pannel stand + one side can move
Cutter:universal cut
Hydraulic pre cut
with 3 sets of holes
Drive ：sprocket+gear
Machine size: L*W*H 11.5m*1.6m*1.4m(approx size. correct size will be known when machineready)
Machine weight about 12Tons
Voltage: 380V/ 3phase/ 50 Hz
