Type:Roof Sheet Roll Forming Machine
Warranty:12 Months
Delivery Time:30 Days
Material:Steel Coil, Galvanized, PPGI, Aluminum
Speed:6-8m/min(including Punching And Cutting Time)
Control System:Panasonic/Mitsubishi PLC
Way Of Driven:Chain Transmission
Cutting Mode:Hydraulic
Material Of Cutting Blade:Cr12
Working Flow: Decoiler – Feeding Guide – Main Roll Forming Machine – PLC Contol System – Hydraulic Punching- Hydraulic Cutting – Output Table
Matching material
Steel coil, Galvanized, PPGI, Aluminum
Material thickness range
According to drawings
Main motor power
30W
Forming speed
10-18min (not include punching and cutting time)
Hydraulic power
7.5KW
Quantity of rollers
About 18
Shaft diameter and material
70mm, material is 45#steel
Material of rollers
Gcr15 or Cr12 with chromed
Way of driven
chain transmission
Controlling system
PLC
Voltage
380V/30Phase/50Hz (as customer require)
Total weight
About 12 tons
Size of the machine
L*W*H 10m*1.2m*1.6m
