Galvanized Purlin Roll Forming Machine in Pennsylvania, USA

The Galvanized Purlin Roll Forming Machine is a robust, high-performance solution designed for the production of structural and industrial purlins. Ideal for Pennsylvania’s construction and manufacturing industry, this machine ensures consistent quality and high-speed output for a variety of profiles.
Whether used in the construction of steel buildings, warehouses, or agricultural structures, this roll forming machine caters to the growing demand for precision and efficiency in the steel fabrication market.
Machine Description
The Galvanized Purlin Roll Forming Machine is engineered for durability and efficiency. Its sturdy 15-ton construction supports the demands of high-speed production while maintaining precision. Equipped with 21 forming stations, the machine ensures seamless shaping and uniformity across the range of purlin profiles.
The Delta PLC system allows for automated operations and easy adjustments, making it user-friendly and reducing downtime. The hydraulic shear ensures clean and precise cuts, suitable for various lengths and specifications. Designed with safety in mind, the machine includes safety covers to protect operators from moving parts during operation.
Profiles and Applications
This machine produces galvanized purlins used in various construction and industrial applications. Below are the key specifications of the profiles:
Profile Range: 5" to 12"

Coil Width: Variable to accommodate different profile requirements

Material Thickness: Adjustable to match project needs

Forming Speed: 50–60 ft/min for high-efficiency output
Applications
Steel building construction
Warehouses
Agricultural facilities
Industrial plants
Roofing and structural support
Key Features for Pennsylvania Businesses
Energy Efficient: Operates on 480V, 3-phase power, suitable for Pennsylvania's industrial power standards.

Customizable Production: Accommodates variable coil widths and material thicknesses, making it versatile for a range of projects in the state’s diverse industries.

Compact Design: Despite its substantial capacity, the machine’s footprint of 60 ft x 12 ft is manageable for most facilities.

High Throughput: With speeds of up to 60 ft/min, it is perfect for large-scale construction projects across Pennsylvania.
Question and Answer Section
Q1: What materials can this machine process?
A1: The machine is optimized for galvanized steel but can process other steel materials as long as they fit the variable coil width and thickness specifications.
Q2: Is this machine suitable for small workshops in Pennsylvania?
A2: While it has a relatively large footprint (60 ft x 12 ft), it can be accommodated in medium to large workshops. Small workshops might require space adjustments.
Q3: Can the machine handle custom profile requirements?
A3: Yes, the variable coil width and material thickness make it adaptable for custom profiles within the specified range of 5" to 12".
Q4: How easy is it to operate the machine?
A4: The Delta PLC control system makes operation straightforward. Operators can easily adjust settings, monitor production, and troubleshoot with minimal training.
Q5: Does it require regular maintenance?
A5: Yes, regular maintenance is necessary to ensure longevity and optimal performance. This includes inspecting the forming stations, lubricating moving parts, and checking the hydraulic system.
Q6: What safety features does the machine offer?
A6: The machine is equipped with safety covers to protect operators from moving components, and it adheres to industrial safety standards.
Q7: Can it be used for other applications besides purlin manufacturing?
A7: While specifically designed for purlin production, its versatility allows it to be adapted for similar profiles within the specified range.

Profile Range: 5" to 12"
Coil Width: Variable
Forming Speed: 50–60 ft/min
Material Thickness: Variable
Machine Weight: 15 tons
Machine Footprint: 60 ft x 12 ft
Main Power: 32 HP, 480V, 3-phase
Stations: 21 forming stations
Cutting Type: Hydraulic shear
Control System: Delta PLC for precise control and automation
Safety Covers: Yes, for enhanced operator safety
