Suitable roll forming material
Color steel sheet or galvanized steel sheet
Thickness
0.8-1.2mm
Feeding width
1219mm
Frame design
Wall-plate-frame-design /Strong-stand-frame-design
Roll stages
26-28 stages
Material of forming roller
45# steel with forge treatment, CNC lathes, Hard Chrome Coated
Embossing rollers made from GCr15+heat treatment, Hard Chrome Coated
Shafts Diameter
Φ95mm
Main motor power
18.5KW*2 with reducer
Max. Line speed of roll former
12-15m/min (Higher speed is available, depends on the specification required by the buyer)
Hydraulic group power
5.5KW
Material of cutting blade
Cr12, heat treatment
Electric Standard
220V /60Hz/3PH or as the customer's requirements
Machine Dimensions
22860mm×4500mm×1600
Major Color of Machine Painted
RAL 5015 (Blue) or as per customer's requirements
(3) PLC Control system
PLC
Siemens brand
Touch Screen
Siemens brand
Inverter
Schneider or Shihlin or Panasonic brand
Encoder
Omron brand
(4) Product rack
Description
un-powered, 6 meters long
