Roof Sheet Roll Forming Machine – United Arab Emirates

Roof Sheet Roll Forming Machine – United Arab Emirates

Precision-Crafted for the UAE's Roofing Industry – Custom-Built & Delivered Nationwide
Product Overview
The Roof Sheet Roll Forming Machine is engineered for producing high-quality metal roofing panels widely used in the residential, commercial, and industrial sectors across the UAE. Built for strength, reliability, and efficiency, this roll forming machine delivers consistent performance in high-output environments such as roofing panel production facilities and metal building manufacturers.
Optimized for the UAE market, this machine is suitable for the production of various popular roof sheet profiles like IBR, corrugated, and trapezoidal panels. All machines are custom-built and delivered directly to Abu Dhabi, Dubai, Sharjah, and other Emirates.
Unique Selling Propositions (USPs) & Advantages
Custom Profile Capability: Machines are tailored to your exact profile drawing—ensuring zero waste and perfect fitment.

Built for UAE Conditions: Electrical systems and machine configurations are adapted to the regional power supply and heat environment.

High-Speed, High-Accuracy Output: Up to 40m/min with ±1mm length tolerance, allowing for fast project turnarounds.

Long-Term Investment Value: Built with hardened and coated rollers for longevity—reducing maintenance frequency and cost.

Flexible Material Compatibility: Supports a wide range of coated and bare steels and aluminum.

After-Sales Peace of Mind: One-year warranty plus lifetime technical support.
Industries Served
Metal Roofing Contractors & Fabricators

Pre-Engineered Metal Building (PEMB) Manufacturers

Steel Construction Companies

Modular and Prefab Building Suppliers

Residential & Commercial Roofing Installers

Steel and Metal Panel Wholesalers
Common Applications:
Roof panels for warehouses, factories, homes, and commercial buildings

Retrofit and repair panels for existing structures

Fast-turnaround custom panel production for UAE construction projects
Machine Technical Specifications
Specification
Detail

Machine Type:
Roof Sheet Roll Forming Machine

Production Speed:
12–40 meters per minute

Material Thickness Range:
0.3 mm – 0.8 mm

Material Width Range:
914 mm – 1250 mm (depends on profile)

Material Types:
Galvanized Steel, Galvalume, Aluminum, Painted Steel

Material Yield Strength:
Up to 550 MPa (80 ksi)

Roller Material:
GCr15 high-grade steel

Roller Surface Treatment:
Hard chrome-plated

Number of Forming Stations:
14–22 stations (customizable)

Roller Shaft Diameter:
70 mm

Shaft Material:
Solid 45# steel, precision machined

Main Drive Type:
Chain or gearbox drive (based on load)

Power – UAE Configuration:
380V / 3 Phase / 50 Hz

Motor Power:
7.5 kW – 15 kW (depends on model)

Cutting Method:
Hydraulic post-cut

Blade Material:
Cr12Mov, heat-treated

Control Type:
PLC system with touchscreen HMI

Operating Mode:
Fully automatic, manual override included

De-coiling System:
Manual or hydraulic uncoiler (optional)

Punching/Notching System:
Optional hydraulic unit before forming

Machine Frame:
Welded steel structure

Frame Steel Thickness:
20 mm

Profile Shape:
Corrugated, Trapezoidal, IBR (customizable)

Profile Width and Depth:
Varies (typically 1000 mm effective cover, 28–45 mm depth)

Length Tolerance:
±1 mm

Safety Features:
Protective covers, Emergency stop, Overload protection
Materials Typically Used
Galvanized Steel (GI): 0.4–0.8 mm | 240–550 MPa

Galvalume: 0.4–0.7 mm | 340–550 MPa

Aluminum: 0.4–0.6 mm | 150–300 MPa

Pre-Painted Steel: 0.3–0.7 mm | 250–350 MPa
Price & Delivery
Prices Start From: USD $36,000

Pricing varies based on profile complexity, automation level, and optional extras.
What Affects Final Price:
Profile design and width

Required output speed

Motor and cutting system type

Punching/notching features

Uncoiler or stacker add-ons

Shipping and installation options
Location: Delivered across UAE, including Dubai, Abu Dhabi, Sharjah, and other Emirates.

All machines are new, custom-built, and backed by a one-year warranty.
Customization Options
Profile tooling for custom roof designs

Servo feeder for higher accuracy

Remote-access PLC control system

Coil car + Hydraulic decoiler

Automatic stacking system

Roofing sheet embossing unit

Extended safety enclosure package
Get a Quote
To receive a tailored quotation, email your profile drawing, material gauge, and expected usage details to:
[email protected]
Frequently Asked Questions (FAQ)
Q: What is the production time for custom-built machines?

A: Production typically takes 30–50 days depending on the level of customization.
Q: Can the machine run aluminum or color-coated sheets?

A: Yes. The rollers and drive system are suitable for aluminum and coated steel.
Q: Do you offer on-site installation in the UAE?

A: Yes, our team or partners provide full installation and training within the UAE.
Q: What kind of profiles can this machine produce?

A: IBR, trapezoidal, corrugated, and any custom roof panel profiles based on your drawing.
Q: Can we include a stacker or an embossing system?

A: Yes, optional extras such as stackers, embossers, and remote PLCs are available.
For more information, custom solutions, or immediate assistance, contact us today and let Machine Matcher connect you to the ideal Roof Sheet Roll Forming Machine for your business in the UAE.
