Description
There are different choices, please turn to the catalogue of un-coiler
(2) Manual Pre-shearing device
Function
un-powered
Dual Leveling
Smart cut control, to cut off the end of the final piece of sheet only
Shearing Thickness
Up to Max. 0.6mm (if thickness > 0.6mm, then hydraulic pre-shearing device or electric pre-shearing device instead )
(3) The general machine parameter
Suitable roll forming material
Color steel sheet or galvanized steel sheet
Thickness
0.4mm-0.6mm
Feeding width
1220mm
Frame design
Wall-plate-frame-design /New-stand-frame-design
Upper Roll stages
20 stages
Lower Roll stages
20 stages
Material of forming roller
45# steel with forge treatment, CNC lathes, Hard Chrome Coated
Shafts Diameter
Φ75/Φ95mm
Main motor power
11KW with reducer
Max. Line speed of roll former
20-25m/min (Higher speed is available, depends on the specification required by the buyer)
Attention:
The two levels can't be run at the same time
Manual Clutch to switch the driven system
The two profiles share one un-coiler/ base frame/ main motor for roll former/ hydraulic cutting carriage/PLC control system
Hydraulic group power
5.5KW
Material of cutting blade
Cr12, heat treatment
Electric Standard
415V /50Hz/3PH or as the customer's requirements
Major Color of Machine Painted
RAL 5015 (Blue) or as per customer's requirements
(4) PLC Control system
PLC
Siemens brand
Touch Screen
Siemens brand
Inverter
Schneider or Shihlin or Panasonic brand
Encoder
Omron brand
(5) Product rack
Description
un-powered, 3 units
