Material
Aluminium PPGI PPGL GI GL
Width
1200mm
Thickness
0.3-0.8mm, customized
Power
380V 3Phase 50Hz, customized
Main Motor
5.5KW, Lichao, Shanghai/Siemens Brand
Cutting Motor
4.0KW, Lichao, Shanghai/Siemens Brand
Support Frame
400H steel, 10mm
Forming Station
18+18rows, exactly according to profile drawing
Structure
16mm
Shaft
45# high grade steel, 80mm, solid, with keyway
Roller
45# high grade steel with heat treatment, hard chrome plated
Chain
1.0inch
Bearing
Standard
Speed
12-18m/min
Electric Components
Delta / Siemens / Mitsubishi
Cutting Blade
Cr12Mov, quenched 58°-62°
Operation
Touch Screen
Dimension
9.1*1.75*2.1M
Weight
9.0T
