Item
Specification
Raw Material
Type
Pre-painted steel coil & galvanized coils
Thickness(mm)
0.3-0.55mm
Roller material
45# steel , coated with Chrome
Shaft for rollers
Solid shaft with 55mm,
processed with cylindrical grinder
Forming speed(m/min)
About 30-35
Speed adjusting mode
Mitsubishi frequency transformer
Roller drive
Decelerating motor + Chain drive
Cutting mode
Hydraulic cutting
Cutter material
Cr12 mov.
Length measurement
Nemicon Encoder
Control mode
Mitsubishi PLC
Operating mode
Button + Mitsubishi Touch screen
Main motor power(kw)
7.5KW
Total power(kw)
9.7KW
Process flow
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table
