WEB Technology Inc CENTRIFUGE SYSTEM 9000
The Series 9000 Centrifuge is the result of WEB Technology’s years of experience with constant acceleration testing of high-reliability semiconductor devices.
Safety, reliability and serviceability are emphasized in the design and construction of this highly-productive system.
The proper combination of drive rotors and fixturing will allow any microelectronic package to be tested per the requirements of Mil Standard 883C, Method 2001, Test Condition
A-E and other equivalent specifications.
FEATURES:
Microprocessor control.
Proven quill-shaft spindle-drive design.
Shunt-wound DC motor, which minimizes service requirements, while greatly prolonging brush life.
Automatic belt-tensioning and alignment mechanism, which eliminates the need for routine adjustments and extends belt life.
Sealed test enclosure designed for safe containment of any potential load separation.
Cycle times of under three minutes are achievable.
Compatibility with existing fixturing.
Set-up configuration data can be entered either manually or pre-programmed and retrieved from the CPU’s memory.
Extensive sensor network monitors all critical operating parameters.
Large 4-line x 40-character LCD status display for continuous test cycle feedback.
