Technical Data
Displacement (swept volume)
60 Hz 6.7cfm
Speed (Pneurop) 60 Hz 5.8 cfm
Ultimate vacuum
without gas ballast 0.75×10-5 torr
(partial pressure)
without gas ballast (totalpressure) 0.75×10-4 torr
with gas ballast (partial
pressure) 2.25×10-2 torr
Inlet connection NW25 flange with 15 mm nozzle alternative
Outlet connection Nozzle 15 mm external diameter
Maximum inlet pressure
for water vapor 11 torr
Weight 50lb
Motor 50 Hz 0.37 kW
Motor 60 Hz 0.37 kW
Oil capacity-maximum 0.55 liter
minimum 0.43 liter
Recommended Edwards oil Supergrade A
