Technical Data
Displacement (swept volume) 60 Hz 1.3 cfm
Speed (Pneurop) 60 Hz 1.1 cfm
Ultimate vacuum
without gas ballast (partial pressure) 3.8 X 10-4 torr
without gas ballast (total pressure) 1.1 x 10-3 torr
with gas ballast (partial pressure) 1.9 x 10-2 torr
Inlet connection NW10 flange
Outlet connection Nozzle 11 mm external
diameter. Hole tapped
Maximum inlet pressure
for water vapor 11 torr
Weight 22 lb
Motor 50 Hz/60 Hz (I P64) 0.16 kW
Oil capacity-maximum 0.28 litres
minimum 0.2 litres
Recommended Edwards oil Supergrade A
