SCHUNK TB 500-205 LH EXTENDED STROKE AIR CHUCK

Schunk part number

0818015

Serial number

083607

Chuck diameter

500 mm (19.68”)

Thru hole

205 mm (8.07 ”)

Spindle nose

flat back

Stroke per jaw

0.66” rapid, 0.33” clamping

Total stroke per jaw

1”

Jaw serrations

3/32 x 90’

Maximum rpm

1,100 rpm

Maximum clamping force

240 kN @ 85 psi.

Weight without top jaw tooling

748 lbs.

Price each:

$18,500. FOB
Houston
,
TX
.


Included with the chuck: Air
distributor ring.


Condition:

Very good to excellent.

30 day return.


Delivery:

Stock, our warehouse.


Mounting package:

--We can also supply a full wrap
around distributor ring mounting bracket (DRMB) for a front mounted
chuck or stand-off brackets for a rear mounted chuck.

We also supply adapter plates and can do the complete
installation if required.

Factory List Price $ 46,361. USD
